Modular partitions engineered for durability, compliance, and adaptability.
Avanteclad delivers modular cleanroom wall solutions designed for industries where ISO 14644, cGMP, FDA, Semiconductor standards, and Solar ISO compliance are non-negotiable.Our cleanroom wall systems provide desired level of airtightness and sealing, non-shedding surfaces and low-outgassing properties which are duly tailored for various critical industrial applications.
These cleanroom walls are available in both Progressive and Non-Progressive configurations:
Avanteclad’s modular wall partitions are designed with a theme of versatility and performance at their core. With panel thickness ranging from 50 mm to 150 mm and height options up to 7000 mm, they adapt seamlessly to diverse almost every cleanroom project’s needs.
Multiple core materials, including Rockwool, PUF, PIR and Aluminum Honeycomb, provide flexibility to meet desired level of thermal insulation, Fire rating and load requirements.
Surface finishes such as Powder-Coated GI, Pre-Painted GI (PPGI) and Stainless Steel ensures the desired level of stain and chemical resistance, ease of cleaning etc.
Provision of factory-integrated return air risers, cutouts and conduits in various options of partitions simplifies the HVAC and electrical integration.
The flush seamless joints deliver clean aesthetics with dust-free surfaces, ensuring long-term operational reliability.
Looking for modular wall solutions tailored to your industry? Fill out the form below and our team will get back to you with a customized quote
011-45508664
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Accelerate timelines, reduce downtime, and stay audit-ready.
0.6 mm pre-painted steel with 20–25µ coating on cleanroom side (30–40% gloss level)
Available from 50 to 100 mm.
Rockwool bats.
Smooth surface, non-shedding material with good chemical resistance.
Height up to 7000 mm; Width 1197 mm (standard) Factory fitted conduits,
2 hour fire testing of panels.
Various load bearing capacities available as per clients specifications.
Lightweight options for rapid installation without compromising the panel strength.
Excellent flatness of panels.
GPSP sheet with 80–120 GSM zinc coating.
60–80µ powder coat (Below 20% gloss level), abrasion and UV resistant.
Available from 50 to 150 mm.
Rockwool bats, PUF, PIR and Honeycomb
Height up to 6000 mm; Width 1197 mm (standard)
Smooth surface, non-shedding material with excellent chemical resistance.
50 mm, 75 mm, 100 mm.
Aluminum Honeycomb
PVDF, Life Antimicrobial, PE and SS
Available in conductive or non-conductive finishes.
Stud-less System, Stud System and Cladding System.
GMP-compliant partitions ensuring sterile production zones.
Low outgassing panels for wafer fabs and chip assembly.
High thermal stability panels for high-throughput manufacturing.
Hygiene-critical walls for Class 100–100K cleanrooms.
Panels engineered for easy sanitation and wash-down resilience.
Client: Exicom
Scope: 25,000 sq. ft. cleanroom wall partitions with integrated return-air risers.
Execution Time: 20 weeks, including design-to-installation.
Result: Achieved Class 100 cleanroom certification while reducing assembly time by 30% vs. conventional systems.
Backed by Avant Garde Cleanroom & Engineering Solutions (ACES).
200,000 sq. m. annual modular partition output.
Advanced renowned brands semi-automated manufacturing line.
Design, production, and installation delivered under one umbrella.
From custom dimensions and infill selection to surface finish variations and integrated utility provisions, every Avanteclad partition system is engineered to fit your operational workflows without compromise.
